FL2010 is a 20 Gbps USB3.2 module based on Infineon EZ-USB FX20 (CYUSB4024). It features an FMC-LPC (VITA57.1) interface for FPGA communication, dual USB ports (USB3.2 + USB2.0 debug), and is widely used in image acquisition, high-speed data transmission, and embedded vision systems.
FL2010 is a high-speed USB3.2 communication module based on the Infineon EZ-USB FX20 (CYUSB4024) controller. It complies with the FMC-LPC (VITA57.1) interface specification and is designed for high-speed data interaction with FPGA development boards. Supporting an upstream data rate of up to 20 Gbps, it features dual USB interfaces (one USB3.2 port and one USB2.0 debug port). It is widely used in applications such as image acquisition, high-speed data transmission, and embedded vision systems.
FL2010 has a standard FMC LPC interface that can be connected to the ALINX FPGA carrier board for use.
● High-speed image acquisition and transmission system
● Data acquisition and upload
● Embedded video device development
● Test & measurement and instrumentation
The FL2010 module is built around the EZ-USB™ FX20 (CYUSB4024) USB3.2 controller as its main processor, and communicates with the FPGA carrier board via the FMC LPC interface. The overall signal flow and functional modules are described as follows.：
Click on the image to view a larger image.
Not all features are available simultaneously – please check the documentation for any applicable constraints.
All specifications are subject to change without notice. Please verify component specifications with vendor's datasheets.
ALINX provides product user manuals for each product.
