ALINX Releases Development Board and SoM with AMD Versal™ AI Edge


Shanghai, China – February 26th, 2024 – ALINX releases the VD100 development board with AMD/Xilinx Versal™ AI Edge VE2302. As one of the Tier-1 SoM (System-on-Module) partners, ALINX works closely with AMD to build the ecosystem. The price of VD100 is fixed at 800 USD to attract more people to utilize and benefit from AMD FPGA and AI technology. Equipped with a multitude of peripherals, with an affordable price, VD100 is the ideal starter’s development board for applications based on AMD’s Versal devices. The pluggable module offers users the flexibility to customize their own carrier boards for mass production. VD100 will be exhibited at Embedded World Nuremberg 2024 in April at AMD’s booth.

The heatsink kit with fan and SD card would be delivered with the development board by default. There are add-on options including AN5020 MIPI camera and AN7000 LVDS LCD to enable users to get started right away.


ALINX's VD100 Development Board Priced at 800 USD


The Versal™ AI Edge series delivers high performance, low latency AI inference for intelligence in automated driving, predictive factory and healthcare systems, multi-mission payloads in aerospace, and a breadth of other applications. As an adaptive compute acceleration platform, it offers AIE-ML and DSP hardware acceleration engines, along with multiple high-speed connectivity options. support a breadth of workloads common in edge applications including AI inference, image processing, and motion control.


Applications of AMD’s Versal™ AI Edge series


The VD100 development board features PCIe3.0 x4, 2 x SFP+ (12.5Gbps per line), 2 x Gigabit Ethernet, 2 x 4 lane MIPI on PL, LVDS LCD, USB 2.0, etc.

VD100 development board with AMD/Xilinx Versal™ AI Edge VE2302

VD100 Development Board with Interface Markings


The V100 SoM is a minimum system ready to run Linux which integrates VE2302 SoC as well as 4GB DDR4 SDRAM, 64MB QSPI Flash and 8GB eMMC Flash. The V100 SoM is connected to the base board via 2 160-pin Samtec board-to-board connectors. With a compact design, V100 is measuring only 65 x 60 mm.

V100 SOM with AMD/Xilinx Versal™ AI Edge VE2302

V100 SoM Top View with Markings



V100 SoM Bottom View with Markings

More information can be found at:
