The AXW22 development board integrates AMD Zynq UltraScale+ XCZU47DR RFSoC with 2-channel 14-bit 5.0GSPS ADCs and 2-channel 14-bit 9.85GSPS DACs for direct RF sampling, combining programmable logic, multi-core ARM processing, and high-speed interfaces (40G QSFP+/10G SFP+) to enable heterogeneous signal processing in radar, 5G, and software-defined radio applications.
Unit price
$ 8066
The AXW22 development board adopts the Zynq UltraScale+ RFSoC Gen3 series XCZU47DR FPGA chip, integrating RF direct sampling data converters, FPGA logic, a multi-core ARM processor subsystem (Quad Cortex-A53 + Dual Cortex-R5), and high-speed transceivers. It supports 2-channel 14-bit RF-ADCs at 5.0 GSPS and 2-channel 14-bit RF-DACs at 9.85GSPS. The board maximizes I/O channel density and bandwidth while enabling heterogeneous processing with optimized power efficiency for RF signal chains.
The AXW22 development board supports prototyping and development for large-scale MIMO systems, 5G baseband processing, fixed wireless access (FWA), DOCSIS 3.x cable access, RF testing and measurement, satellite communication systems, phased array radar (prototyping), and digital array radar systems, alongside other high-performance RF applications
● 5G FR1 RF and baseband prototyping
● Phased array radar signal processing (subsystem)
● Digital radar signal processing
● software radio
● Wideband spectrum sensing
Design-in Kit – The Fast Way to the Market, to get started with development straight out of the box.
The ALINX development board help shorten time-to-market for any AMD/Xilinx Zynq™ UltraScale+™ RFSoC based application.
Heatsink Kit is an optimal cooling solution for ALINX FPGA and SoC modules – it is low-profile and covers the whole module surface.
| Development Board | 1 | Heatsink Kit (preinstalled) | 1 |
|---|---|---|---|
| SMA cable | 1 | Network cable | 1 |
| SD card | 1 | The power adapter | 1 |
| Data USB flash drive | 1 |
| Product Model | Preferred Model | FPGA Devices | DDR4 SDRAM (PS) | DDR4 SDRAM (PL) | QSPI Flash | RF-ADC | RF-DAC | GTY | GTR | USD Price | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| AXW22 | √ | XCZU47DR-2FFVE1156I | 4 GB | 2 GB | 256 MB | 2 | 2 | 8 | 4 | 8066 |
1. For non-preferred models, a minimum order quantity (MOQ) may apply if the products are not in stock.
2. We offer custom configuration, a MOQ applies.
Please contact us for more details.
We offer complete documentations and a lot of demos and tutorials.
Please contact us should you have any need.
