FH9656

Key Features

• ● 8 channels, 16-bit, 125 MSPS sampling rate
  ● Single-ended AC-coupled input
  ● Input Voltage Range: 2.0 Vpp to 2.8 Vpp
  ● Analog Input Bandwidth: 650 MHz
  ● Signal-to-Noise Ratio (SNR): 79.9 dBFS (at 16 MHz, Vref=1.4V)
  ● Signal-to-Noise Ratio (SNR): 78.1 dBFS (at 64 MHz, Vref=1.4V)
  ● Spurious-Free Dynamic Range (SFDR): 86 dBc (to Nyquist )
  ● ENOB @ 9.7 MHz: 12.9 bits
  ● Standard FMC mezzanine card, compliant with VITA57.1
  ● On-board EEPROM (1 device)
  ● FMC Connector Model: ASP-134488-01 (HPC)
  ● Power Supply: +12 V, Typical Board Power: 4 W
• ● Internal reference voltage source of ADC
  ● Mixed JESD204B Lane configuration
  ● Supports three modes: Local Reference, External Reference Input, External VCO Input
  ● On-board high-precision clock chip: HMC7044
  ● Supports external trigger
  ● On-board status indicator(s)
  ● Board Dimensions: 84.1 mm x 69 mm
  ● Power Supply: +12 V (±5%), Power Consumption＜7 W
  ● Cooling Method: Natural convection or metal conduction cooling
  ● Operating temperature: -40 °C~+85 °C
  ● Storage temperature: -55 °C~+125 °C
  ● Operating humidity: 5%~95%, non condensing
